TIANMA 5.7 inch 640x480 TFT LCD Screen TM057QDH01 with 400 nits and 33 pin RGB

TIANMA 5.7 inch 640x480 TFT LCD Screen TM057QDH01 with 400 nits and 33 pin RGB
TIANMA 5.7 inch 640x480 TFT LCD Screen TM057QDH01 with 400 nits and 33 pin RGB
  • Stock: In Stock
  • Model: TM057QDH01
  • Weight: 0.75kg
  • Dimensions: 32.00cm x 22.00cm x 9.00cm
  • SKU: TM057QDH01
  • UPC: TM057QDH01
  • JAN: TM057QDH01
  • ISBN: TM057QDH01
  • MPN: TM057QDH01
Products Sold: 0
Product Views: 141
0 reviews - Write a review
$999.99
Ex Tax: $999.99
Price in reward points: 24
Add to Cart
Buy Now Ask Question
Add to Wish List Compare this Product
Manufacturer  TIANMA
Model Name TM057QDH01
Screen Size 5.7 inch
Pixel Number 640(RGB)×480,VGA
Active Area(mm) 115.20(H) x 86.40(V)
Outline(mm） 144(H) x 104.6(V) x 12.3(D)
Pixel Pitch(mm) 0.18 x 0.18
Treatment Anti-Glare,Hardness 3H
Luminance 400 cd/m² (Typ.)
Contrast Ratio 500 : 1 (Typ.) (TM)
Viewing Angle 70/70/70/60(CR≥10) Left / Right/UP /Down
Response 20 (Typ.)(Tr/Td) ms
Work Mode TN, Normally white, Transmissive
Color Depth 262K,50% NTSC
Backlight WLED, 50K hours,without driver
Net Weight 165g
Touchscreen without
Signal Type/interface Type Parallel RGB (1 ch, 6-bit),33 pins
Voltage Supply 3.3V
Max. Ratings Storage Temp.: -30 ~ +80 (°C)
Operating Temp.: -20 ~ +70 (°C)
Package TIANMA original package
